Unlock Microcontroller MCU

We can unlock microcontroller PIC24FJ16GA002 – 28/44-Pin General Purpose, 16-Bit Flash Microcontrollers MCU, please view IC chip features for your reference:



High-Performance CPU

· Modified Harvard Architecture

· Up to 16 MIPS Operation @ 32 MHz

· 8 MHz Internal Oscillator with 4x PLL Option and

Multiple Divide Options

· 17-Bit by 17-Bit Single-Cycle Hardware Multiplier

· 32-Bit by 16-Bit Hardware Divider

· 16-Bit x 16-Bit Working Register Array

· C Compiler Optimized Instruction Set Architecture:

– 76 base instructions

Flexible addressing modes

· Two Address Generation Units (AGUs) for Separate Read and Write Addressing of Data Memory

Special Microcontroller Features

Analog Features

· 10-Bit, up to 13-Channel Analog-to-Digital Converter:

– 500 ksps conversion rate

– Conversion available during Sleep and Idle

· Dual Analog Comparators with Programmable Input/Output Configuration

Peripheral Features

· Peripheral Pin Select (PPS):

– Allows independent I/O mapping of many peripherals

– Up to 26 available pins (44-pin devices)

– Continuous hardware integrity checking and safety interlocks prevent unintentional configuration changes

· 8-Bit Parallel Master/Slave Port (PMP/PSP):

– Up to 16-bit multiplexed addressing, with up to Operating Voltage Range of 2.0V to 3.6V 5.5V Tolerant Input (digital pins only)

High-Current Sink/Source (18 mA/18 mA) on All I/O Pins Flash Program Memory:

– 10,000 erase/write

20-year data retention minimum

Power Management modes:

– Sleep, Idle, Doze and Alternate Clock modes

– Operating current: 650 mA/MIPS, typical at 2.0V

– Sleep current: 150 nA, typical at 2.0V

Fail-Safe Clock Monitor (FSCM) Operation:

Detects clock failure and switches to on-chip, low-power RC oscillator On-Chip, 2.5V Regulator with Tracking mode

Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST) Flexible Watchdog Timer (WDT) with On-Chip, Low-Power RC Oscillator for Reliable Operation In-Circuit Serial Programming™ (ICSP™) and In-Circuit Debug (ICD) via 2 Pins JTAG Boundary Scan Support



11 dedicated address pins on 44-pin devices

– Programmable polarity on control lines

· Hardware Real-Time Clock/Calendar (RTCC):

– Provides clock, calendar and alarm functions

· Programmable Cyclic Redundancy Check (CRC)

· Two 3-Wire/4-Wire SPI modules (support 4 Frame modes) with 8-Level FIFO Buffer

· Two I2C™ modules Support Multi-Master/Slave mode and 7-Bit/10-Bit Addressing

· Two UART modules:

– Supports RS-485, RS-232, and LIN/J2602

– On-chip hardware encoder/decoder for IrDA®

– Auto-wake-up on Start bit

– Auto-Baud Detect

– 4-level deep FIFO buffer

· Five 16-Bit Timers/Counters with Programmable Prescaler

· Five 16-Bit Capture Inputs

· Five 16-Bit Compare/PWM Outputs

· Configurable Open-Drain Outputs on Digital I/O Pins

· Up to 3 External Interrupt Sources
