Unlock IC PIC18F6390 Software

Unlock IC PIC18F6390 through reverse engineering Microcontroller structure, locate the security fuse bit of Microcontroller and readout the Software from its memory;

Unlock IC PIC18F6390 Software

Unlock IC PIC18F6390 Software

LCD Driver Module Features:

· Direct Driving of LCD Panel

· Up to 48 Segments: Software Selectable

· Programmable LCD Timing module:

– Multiple LCD timing sources available

– Up to 4 commons: Static, 1/2, 1/3 or 1/4 multiplex

– Static, 1/2 or 1/3 bias configuration

· Can drive LCD Panel while in Sleep mode

Power-Managed Modes:

· Run: CPU On, Peripherals On

· Idle: CPU Off, Peripherals On

High-Current Sink/Source 25 mA/25 mA

Four External Interrupts

Four Input Change Interrupts

Four 8-Bit/16-Bit Timer/Counter modules

Real-Time Clock (RTC) Software module:

– Configurable 24-hour clock, calendar, automatic 100-year or 12800-year, day-of-week calculator

– Uses Timer1

Up to 2 Capture/Compare/PWM (CCP) modules

Master Synchronous Serial Port (MSSP) module supporting 3-Wire SPI (all 4 modes) and I2C™

Master and Slave modes

Sleep: CPU Off, Peripherals Off

Run mode Currents Down to 14.0 ìA Typical

Idle mode Currents Down to 5.8 ìA Typical

Timer1 Oscillator: 1.8 ìA, 32 kHz, 2V

Watchdog Timer: 2.1 ìA

Addressable USART module:

– Supports RS-485 and RS-232

Enhanced Addressable USART module:

– Supports RS-485, RS-232 and LIN 1.2

– Auto-wake-up on Start bit

– Auto-Baud Detect

· Two-Speed Oscillator Start-up



Flexible Oscillator Structure:

· Four Crystal modes:

– LP: up to 200 kHz 10-Bit, up to 12-Channel Analog-to-Digital (A/D) Converter module:

– Auto-acquisition capability

– Conversion available during Sleep

Dual Analog Comparators with Input Multiplexing

– XT: up to 4 MHz

– HS: up to 40 MHz

– HSPLL: 4-10 MHz (16-40 MHz internal)

· 4x Phase Lock Loop (available for crystal and internal oscillators)

· Two External RC modes, up to 4 MHz

· Two External Clock modes, up to 40 MHz

· Internal Oscillator Block:

– 8 user-selectable frequencies, from 31 kHz to 8 MHz

– Provides a complete range of clock speeds from 31 kHz to 32 MHz when used with PLL

– User-tunable to compensate for frequency drift

· Secondary Oscillator using Timer1 @ 32 kHz

· Fail-Safe Clock Monitor:

– Allows for safe shut down of device if primary or secondary clock fails  in the process of IC code extraction
