Unlock IC PIC18F2439 flash and eeprom memory, then readout the firmware from its memory in the format of Binary or heximal, copy the content into other blank Microcontroller which will provide the same functions as original versions;

High Performance RISC CPU:

· Linear program memory addressing to 24 Kbytes

· Linear data memory addressing to 1.4 Kbytes

· 20 MHz operation (5 MIPs):

– 20 MHz oscillator/clock input

– 5 MHz oscillator/clock input with PLL active

· 16-bit wide instructions, 8-bit wide data path

· 8 x 8 Single Cycle Hardware Multiplier

Special Microcontroller Features:

· 100,000 erase/write cycle Enhanced FLASH program memory typical

· 1,000,000 erase/write cycle Data EEPROM memory

· FLASH/Data EEPROM Retention: > 100 years

· Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

· Programmable code protection

· Power saving SLEEP mode if Unlock IC

· Single supply 5V In-Circuit Serial Programming™ (ICSP™) via two pins

· In-Circuit Debug (ICD) via two pins

Analog Features:

· Compatible 10-bit Analog-to-Digital Converter module (A/D) with:

– Fast sampling rate

– Conversion available during SLEEP

– DNL = ±1 LSb, INL = ±1 LSb

· Programmable Low Voltage Detection (PLVD)

– Supports interrupt on Low Voltage Detection

· Programmable Brown-out Reset (BOR) which can be applied for IC code extraction

Peripheral Features:

· High current sink/source 25 mA/25 mA

· Three external interrupt pins

· Timer0 module: 8-bit/16-bit timer/counter with 8-bit programmable prescaler

· Timer1 module: 16-bit timer/counter

· Timer3 module: 16-bit timer/counter

· Secondary oscillator clock option – Timer1/Timer3

· Two PWM modules:

– Resolution is 1- to 10-bit, Max. PWM freq. @ 8-bit resolution = 156 kHz 10-bit resolution = 39 kHz

· Single Phase Induction Motor Control kernel

– Programmable Motor Control Technology (ProMPT™) provides open loop Variable Frequency (VF) control

– User programmable Voltage vs. Frequency curve

– Most suitable for shaded pole and permanent split capacitor type motors

· Master Synchronous Serial Port (MSSP) module with two modes of operation:

– 3-wire SPI™ (supports all 4 SPI modes)

– I2C™ Master and Slave mode

· Addressable USART module:

– Supports RS-485 and RS-232

· Parallel Slave Port (PSP) module

CMOS Technology:

· Low power, high speed FLASH/EEPROM technology

· Fully static design

· Wide operating voltage range (2.0V to 5.5V)

· Industrial and Extended temperature ranges
