Reverse Engineering CPLD IC GAL16V8D

We can reverse engineering CPLD IC GAL16V8D, please view below chip features for your reference:

HIGH PERFORMANCE E2CMOS® TECHNOLOGY

— 3.5 ns Maximum Propagation Delay

— Fmax = 250 MHz

3.0 ns Maximum from Clock Input to Data Output

— UltraMOS® Advanced CMOS Technology

· 50% to 75% REDUCTION IN POWER FROM BIPOLAR

— 75mA Typ Icc on Low Power Device

45mA Typ Icc on Quarter Power Device

· ACTIVE PULL-UPS ON ALL PINS

· E2 CELL TECHNOLOGY

— Reconfigurable Logic

Reprogrammable Cells

— 100% Tested/100% Yields

High Speed Electrical Erasure (<100ms)

— 20 Year Data Retention

· EIGHT OUTPUT LOGIC MACROCELLS

— Maximum Flexibility for Complex Logic Designs

— Programmable Output Polarity

— Also Emulates 20-pin PAL® Devices with Full Function/Fuse Map/Parametric Compatibility

· PRELOAD AND POWER-ON RESET OF ALL REGISTERS

— 100% Functional Testability

· APPLICATIONS INCLUDE:

— State Machine Control

— High Speed Graphics Processing

— Standard Logic Speed Upgrade

· ELECTRONIC SIGNATURE FOR IDENTIFICATION

· LEAD-FREE PACKAGE OPTIONS
