Retrieve Microcontroller Microchip PIC24FJ16GA002 Code from both its eeprom and flash, then transfer it to other blank PIC24FJ16GA002:
Graphics Controller Features:
· Three Graphics Hardware Accelerators to Facilitate
Rendering of Block Copying, Text and Unpacking of Compressed Data
· Color Look-up Table (CLUT) with Maximum of 256 Entries
· 1/2/4/8/16 bits-per-pixel (bpp) Color Depth Set at Run Time
· Display Resolution Programmable According to Frame Buffer:
– Supports direct access to external memory on devices with EPMP
– Resolution supported is up to 480×272 @ 60 Hz, 16 bpp; 640×480 @ 30 Hz, 16 bpp or 640×480 @ 60 Hz, 8 bpp
· Supports Various Display Interfaces:
– 4/8/16-bit Color STN
– 9/12/18/24-bit Color TFT (18 and 24-bit displays are connected as 16-bit, 5-6-5 RGB color format)
Universal Serial Bus Features:
· USB v2.0 On-The-Go (OTG) Compliant
· Dual Role Capable – Can act as either Host or Peripheral
· Low-Speed (1.5 Mbps) and Full-Speed (12 Mbps) USB Operation in Host mode
· Full-Speed USB Operation in Device mode
· High-Precision PLL for USB
· Supports up to 32 Endpoints (16 bidirectional):
– USB module can use the internal RAM location from 0x800 to 0xFFFF as USB endpoint buffers
· On-Chip USB Transceiver with Interface for Off-Chip Transceiver
· Supports Control, Interrupt, Isochronous and Bulk Transfers
· On-Chip Pull-up and Pull-Down Resistors
Peripheral Features:
· Enhanced Parallel Master Port/Parallel Slave Port (EPMP/PSP), 100-pin devices only:
– Direct access from CPU with an Extended Data Space (EDS) interface
– 4, 8 and 16-bit wide data bus
– Up to 23 programmable address lines
– Up to 2 Acknowledgement lines (one per chip select)
– Programmable address/data multiplexing
– Programmable address and data Wait states
– Programmable polarity on control signals
– Up to 44 available pins (100-pin devices)
· Three 3-Wire/4-Wire SPI modules (supports 4 Frame modes)
· Three I2C™ modules Supporting Multi-Master/Slave modes and 7-Bit/10-Bit Addressing
· Four UART modules:
– Supports RS-485, RS-232, LIN/J2602 protocols and IrDA
· Five 16-Bit Timers/Counters with Programmable Prescaler
· Nine 16-Bit Capture Inputs, each with a Dedicated Time Base
· Nine 16-Bit Compare/PWM Outputs, each with a Dedicated Time Base
· Hardware Real-Time Clock and Calendar (RTCC)
· Enhanced Programmable Cyclic Redundancy Check (CRC) Generator
· Up to 5 External Interrupt Sources
