We can Restore Siemens C505CA-4EM 8-Bit CMOS Microcontroller, please view the IC chip features for your reference:



Fully compatible to standard 8051 microcontroller

· Superset of the 8051 architecture with 8 datapointers

· Up to 20 MHz operating frequency

– 375 ns instruction cycle time @16 MHz

300 ns instruction cycle time @20 MHz (50 % duty cycle)

· On-chip program memory (with optional memory protection)

– C505-2R/C505C-2R :   16k byte on-chip ROM

– C505A-4E/C505CA-4E: 32k byte on-chip OTP

– alternatively up to 64k byte external program memory

· 256 byte on-chip RAM

· On-chip XRAM

– C505/C505C :    256 byte

– C505A/C505CA : 1K byte

· 32 + 2 digital I/O lines

– Four 8-bit digital I/O ports

– One 2-bit digital I/O port (port 4)

– Port 1 with mixed analog/digital I/O capability

Three 16-bit timers/counters

– Timer 0 / 1 (C501 compatible)

Timer 2 with 4 channels for 16-bit capture/compare operation

· Full duplex serial interface with programmable baudrate generator (USART)

· Full CAN Module, version 2.0 B compliant (C505C and C505CA only)

– 256 register/data bytes located in external data memory area

– 1 MBaud CAN baudrate when operating frequency is equal to or above 8 MHz

– internal CAN clock prescaler when input frequency is over 10 MHz

· On-chip A/D Converter

– up to 8 analog inputs

– C505/C505C : 8-bit resolution

– C505A/C505CA: 10-bit resolution

· Twelve interrupt sources with four priority levels

· On-chip emulation support logic (Enhanced Hooks Technology TM 1))

· Programmable 15-bit watchdog timer

· Oscillator watchdog

· Fast power on reset

· Power Saving Modes

– Slow-down mode

– Idle mode (can be combined with slow-down mode)

– Software power-down mode with wake up capability through P3.2/INT0 or P4.1/RXDC pin

· P-MQFP-44 package

· Pin configuration is compatible to C501, C504, C511/C513-family

· Temperature ranges:



SAB-C505 versions

SAF-C505 versions

SAH-C505 versions

SAK-C505 versions



TA = 0 to 70 °C

TA = – 40 to 85 °C

TA = – 40 to 110 °C (max. operating frequency: TBD)

TA = – 40 to 125 °C (max. operating frequency: 12 MHz with 50% duty cycle)
