Recover DSP IC Microchip dsPIC30F6010AT

Recover DSP IC Microchip dsPIC30F6010AT

Recover DSP IC Microchip dsPIC30F6010AT means restore the content of its heximal from both eeprom and flash, please check its features below:

High-Performance Modified RISC CPU:

· Modified Harvard architecture

· C compiler optimized instruction set architecture with flexible Addressing modes

· 83 base instructions

· 24-bit wide instructions, 16-bit wide data path

· 144 Kbytes on-chip Flash program space (Instruction words)

· 8 Kbytes of on-chip data RAM

· 4 Kbytes of nonvolatile data EEPROM

· Up to 30 MIPS operation:

– DC to 40 MHz external clock input

– 4 MHz-10 MHz oscillator input with PLL active (4x, 8x, 16x)

– 7.37 MHz internal RC with PLL active (4x, 8x, 16x)

· 44 interrupt sources:

5 external interrupt sources



· High-current sink/source I/O pins: 25 mA/25 mA

· Timer module with programmable prescaler:

– Five 16-bit timers/counters; optionally pair 16-bit timers into 32-bit timer modules

· 16-bit Capture input functions

· 16-bit Compare/PWM output functions

· 3-wire SPI modules (supports 4 Frame modes)

· I2CTM module supports Multi-Master/Slave mode and 7-bit/10-bit addressing

· 2 UART modules with FIFO Buffers

· 2 CAN modules, 2.0B compliant (dsPIC306010A)

· 1 CAN module, 2.0B compliant (dsPIC306015)

Motor Control PWM Module Features:

· 8 PWM output channels:

– Complementary or Independent Output modes

– Edge and Center-Aligned modes

· 4 duty cycle generators

· Dedicated time base

· Programmable output polarity

· Dead-Time control for Complementary mode

· Manual output control

· Trigger for A/D conversions

Quadrature Encoder Interface Module Features:


– 8 user selectable priority levels for each interrupt source

4 processor trap sources

· 16 x 16-bit working register array

DSP Engine Features:



Phase A, Phase B and Index Pulse input 16-bit up/down position counter

Count direction status

Position Measurement (x2 and x4) mode

Programmable digital noise filters on inputs

Alternate 16-bit Timer/Counter mode



Dual data fetch

Interrupt on position counter rollover/underflow

Accumulator write-back for DSP operations

Modulo and Bit-Reversed Addressing modes

Two, 40-bit wide accumulators with optional saturation logic



Analog Features:

· 10-bit Analog-to-Digital Converter (ADC) with 4 S/H Inputs:

· 17-bit x 17-bit single-cycle hardware fractional
