In order to be able to read IC PIC12F635 program out from its flash memory, microcontroller PIC12F635 encrypted protection must be break so the firmware can be dump directly by a universal programmer or download cable;

High-Performance RISC CPU:

· Only 35 instructions to learn:

– All single-cycle instructions except branches

· Operating speed:

– DC – 20 MHz oscillator/clock input

– DC – 200 ns instruction cycle

· Interrupt capability

· 8-level deep hardware stack

· Direct, Indirect and Relative Addressing modes

Special Microcontroller Features:

· Precision Internal Oscillator:

– Factory calibrated to ±1%

– Software selectable frequency range of 8 MHz to 31 kHz

– Software tunable

– Two-Speed Start-up mode

– Crystal fail detect for critical applications

· Clock mode switching for low power operation

· Power-saving Sleep mode

· Wide operating voltage range (2.0V-5.5V)

· Industrial and Extended Temperature range

· Power-on Reset (POR)

· Wake-up Reset (WUR)

· Independent weak pull-up/pull-down resistors

· Programmable Low-Voltage Detect (PLVD)

· Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

· Brown-out Detect (BOD) with software control option

· Enhanced Low-Current Watchdog Timer (WDT) with on-chip oscillator (software selectable nominal 268 seconds with full prescaler) with software enable

· Multiplexed Master Clear with pull-up/input pin

· Programmable code protection (program and data independent)

· High-Endurance Flash/EEPROM cell:

– 100,000 write Flash endurance

– 1,000,000 write EEPROM endurance

– Flash/Data EEPROM Retention: > 40 years

Low Power Features:

· Standby Current:

– 1 nA @ 2.0V, typical

· Operating Current:

– 8.5 ìA @ 32 kHz, 2.0V, typical

– 100 ìA @ 1 MHz, 2.0V, typical

· Watchdog Timer Current:

– 1 ìA @ 2.0V, typical
