Hack Microchip IC PIC16F876A Binary

Hack Microchip IC PIC16F876A protective system and break mcu pic16f876a fuse bit, read the embedded heximal from microcontroller pic16f876a flash and eeprom memory;

Hack Microchip IC PIC16F876A protective system and break mcu pic16f876a  fuse bit, read the embedded heximal from microcontroller pic16f876a flash and eeprom memory
Hack Microchip IC PIC16F876A protective system and break mcu pic16f876a fuse bit, read the embedded heximal from microcontroller pic16f876a flash and eeprom memory

MEMORY ORGANIZATION

There are three memory blocks in each of the PIC16F87XA devices. The program memory and data memory have separate buses so that concurrent access can occur and is detailed in this section. The EEPROM data memory block is detailed in Section 3.0.

“Data EEPROM and Flash Program Memory”. Additional information on device memory may be found in the PICmicro® Mid-Range MCU Family Reference Manual (DS33023). after Hack atmel attiny861 microcontroller memory protection

PROGRAM MEMORY ORGANIZATION

The PIC16F87XA devices have a 13-bit program counter capable of addressing an 8K word x 14 bit program memory space. The PIC16F876A/877A devices have 8K words x 14 bits of Flash program memory, while PIC16F873A/874A devices have 4K words x 14 bits. Accessing a location above the physically implemented address will cause a wraparound.

break pic16f876a mcu smd fuse bit and copy heximal or binary file from flash and eeprom memory
break pic16f876a mcu smd fuse bit and copy heximal or binary file from flash and eeprom memory

The Reset vector is at 0000h and the interrupt vector is at 0004h.

DATA MEMORY ORGANIZATION

The data memory is partitioned into multiple banks which contain the General Purpose Registers and the Special Function Registers. Bits RP1 (Status<6>) and RP0 (Status<5>) are the bank select bits.

Each bank extends up to 7Fh (128 bytes). The lower locations of each bank are reserved for the Special Function Registers. Above the Special Function Registers are General Purpose Registers, implemented as static RAM. All implemented banks contain Special Function Registers. Some frequently used Special Function Registers from one bank may be mirrored in another bank for code reduction and quicker access.

reverse pic16f876a mcu dip protection and restore embedded firmware code from flash memory
reverse pic16f876a mcu dip protection and restore embedded firmware code from flash memory

The Special Function Registers are registers used by the CPU and peripheral modules for controlling the desired operation of the device. These registers are implemented as static RAM.

The Special Function Registers can be classified into two sets: core (CPU) and peripheral. Those registers associated with the core functions are described in detail in this section. Those related to the operation of the peripheral features are described in detail in the peripheral features section.
