We can Extract Microcomputer IC Renasas HD64F3664FPV, please view below chip features for your reference:
Upward-compatible with H8/300 CPU on an object level
Sixteen 16-bit general registers
· Various peripheral functions
Timer V (8-bit timer)
Timer W (16-bit timer)
Watchdog timer
SCI3 (Asynchronous or clocked synchronous serial communication interface)
I2C Bus Interface (conforms to the I2C bus interface format that is advocated by Philips Electronics)
Product Classification
Model EEPROM ROM RAM
H8/3663
H8/3661
H8/3660
HD6433663
HD6433662
HD6433661
HD6433660
24 kbytes
16 kbytes
12 kbytes
8 kbytes
1,024 bytes
512 bytes
512 bytes
512 bytes
I/O pins: 29 I/O pins (H8/3664N has 27 I/O pins), including 8 large current ports (IOL = 20mA, @VOL = 1.5 V)
Input-only pins: 8 input pins (also used for analog input)
I2C Bus Interface (conforms to the I2C bus interface format that is advocated by Philips Electronics)
Note: F-ZTATTM is a trademark of Renesas Technology Corp.
Package
Code
Body Size
Pin Pitch
LQFP-64
0.5 mm
QFP-64
FP-64A
LQFP-48
LQFP-48
SDIP-42
