Discover Microcomputer IC Infineon SAK-XC167CI-32F40F embedded firmware and then try to readout it:

On-Chip Memory Modules

– 2 Kbytes On-Chip Dual-Port RAM (DPRAM)

– 4 Kbytes On-Chip Data SRAM (DSRAM)

– 6 Kbytes On-Chip Program/Data SRAM (PSRAM)

256 Kbytes On-Chip Program Memory (Flash Memory)

On-Chip Peripheral Modules

– 16-Channel A/D Converter with Programmable Resolution (10-bit or 8-bit) and Conversion Time (down to 2.55 µs or 2.15 µs)

– Two 16-Channel General Purpose Capture/Compare Units (32 Input/Output Pins)

– Capture/Compare Unit for flexible PWM Signal Generation (CAPCOM6) (3/6 Capture/Compare Channels and 1 Compare Channel)

– Multi-Functional General Purpose Timer Unit with 5 Timers

– Two Synchronous/Asynchronous Serial Channels (USARTs)

– Two High-Speed-Synchronous Serial Channels

On-Chip TwinCAN Interface (Rev. 2.0B active) with 32 Message Objects (Full CAN/Basic CAN) on Two CAN Nodes, and Gateway Functionality

– IIC Bus Interface (10-bit addressing, 400 kbit/s) with 3 Channels (multiplexed)

– On-Chip Real Time Clock, Driven by Dedicated Oscillator Idle, Sleep, and Power Down Modes with Flexible Power Management

Programmable Watchdog Timer and Oscillator Watchdog



Up to 12 Mbytes External Address Space for Code and Data

– Programmable External Bus Characteristics for Different Address Ranges

Multiplexed or Demultiplexed External Address/Data Buses

– Selectable Address Bus Width

– 16-bit or 8-bit Data Bus Width

– Five Programmable Chip-Select Signals

– Hold- and Hold-Acknowledge Bus Arbitration Support

Up to 103 General Purpose I/O Lines, partly with Selectable Input Thresholds and Hysteresis On-Chip Bootstrap Loader Supported by a Large Range of Development Tools like C-Compilers, Macro-Assembler Packages, Emulators, Evaluation Boards, HLL-Debuggers, Simulators, Logic Analyzer Disassemblers, Programming Boards On-Chip Debug Support via JTAG Interface 144-Pin TQFP Package, 0.5 mm (19.7 mil) pitch
