There are three full compare units on TMS320F28069. These compare units use GP timer1 as the timebase and generate six outputs for compare and PWM-waveform generation using programmable deadband circuit. The state of each of the six outputs is configured independently by Crack TMS320F28069 Microcomputer Memory. The compare registers of the compare units are double-buffered, allowing programmable change of the compare/PWM pulse widths as needed.

The deadband generator circuit includes three 8-bit counters and an 8-bit compare register. Desired deadband value (from 0 to 102 s) can be programmed into the compare register for the outputs of the three compare units in order to Restore DSP CPU TMS320F28030PAGT Source Code. The deadband generation can be enabled/disabled for each compare unit output individually.

The deadband-generator circuit produces two outputs (with or without deadband zone) for each compare unit output signal. The output states of the deadband generator are configurable and changeable as needed by way of the double-buffered ACTR register when Reading MCU.

Crack TMS320F28069 Microcomputer Memory

TMS320F28069 is equipped with three simple compares that can be used to generate three additional independent compare or high-precision PWM waveforms from Crack TMS320F28069 Microcomputer Memory. GP timer1 or 2 can be selected as the timebase for the three simple compares.

The states of the outputs of the three simple compares are configurable as low-active, high-active, forced-low, or forced-high independently. Simple compare registers are double-buffered in the process of DSP Processor TMS320F2401AVFA Program Cloning, allowing programmable change of the compare/PWM pulse widths as needed. The state of the simple-compare outputs is configurable and changeable as needed by way of the double-buffered SACTR register.

Up to 12 compare and/or PWM waveforms (outputs) can be generated simultaneously by TMS320F28069: three independent pairs (six outputs) by the three full compare units with programmable deadbands by the effect of Crack DSP Controller TMS320F243PGEA, three independent compares or PWMs (three outputs) by the simple compares, and three independent compare and PWMs (three outputs) by the GP-timer compares.
