Microcontroller Core Features:

· High-performance RISC CPU

· Only 35 single word instructions to learn

· All single cycle instructions except for program branches which are two cycle

· Operating speed: DC – 20 MHz clock input DC – 200 ns instruction cycle

· Interrupt capability (up to 7 internal/external interrupt sources)

· Eight level deep hardware stack

· Direct, indirect and relative addressing modes

· Power-on Reset (POR)

· Power-up Timer (PWRT) and Oscillator Start-up Timer (OST) if Crack MCU

· Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation

· Brown-out detection circuitry for Brown-out Reset (BOR)

· Programmable code-protection

· Power saving SLEEP mode

· Selectable oscillator options

· Low-power, high-speed CMOS EPROM technology

· Fully static design

· In-Circuit Serial Programming™ (ICSP)

· Wide operating voltage range: 2.5V to 5.5V

· High Sink/Source Current 25/25 mA

· Commercial, Industrial and Extended temperature ranges

· Low-power consumption:

– < 2 mA @ 5V, 4 MHz

– 22.5 µA typical @ 3V, 32 kHz

– < 1 µA typical standby current

Peripheral Features:

· Timer0: 8-bit timer/counter with 8-bit prescaler before Crack pic16f620a MCU

· Timer1: 16-bit timer/counter with prescaler can be incremented during sleep via external crystal/clock

· Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler

· Capture, Compare, PWM module

· Capture is 16-bit, max. resolution is 12.5 ns, Compare is 16-bit, max. resolution is 200 ns, PWM maximum resolution is 10-bit

· 8-bit multi-channel Analog-to-Digital converter

This document contains device-specific information. Additional information may be found in the PICmicro™ Mid-Range Reference Manual, (DS33023), which may be obtained from your local Microchip Sales Representative or downloaded from the Microchip website. The Reference Manual should be considered a complementary document to this data sheet, and is highly recommended reading for a better understanding of the device architecture and operation of the peripheral modules before unlock pic16c622a MCU.

There are two devices (PIC16C712, PIC16C716) covered by this datasheet. Figure 1-1 is the block diagram for both devices. The pinouts are listed in Table 1-1.
