Crack MCU IC P87C51X2BBD

Crack MCU IC P87C51X2BBD needs to disable the security fuse bit of the MCU and then readout the firmware from its memory which include the flash and eeprom:

FEATURES

  • · 80C51 Central Processing Unit

4 kbytes ROM/EPROM (P80/P87C51X2)

8 kbytes ROM/EPROM (P80/P87C52X2)

16 kbytes ROM/EPROM (P80/P87C54X2)

32 kbytes ROM/EPROM (P80/P87C58X2)

128 byte RAM (P80/P87C51X2 and P80C31X2)

256 byte RAM (P80/P87C52/54X2/58X2 and P80C32X2)

Boolean processor

Fully static operation

Crack MCU IC P87C51X2BBD

Crack MCU IC P87C51X2BBD

Low voltage (2.7 V to 5.5 V at 16 MHz) operation

  • · 12-clock operation with selectable 6-clock operation (via software or via parallel programmer)
  • · Memory addressing capability

Up to 64 kbytes ROM and 64 kbytes RAM

  • · Power control modes:

Clock can be stopped and resumed

Idle mode

Power-down mode

0 to 30 MHz with 6-clock operation

0 to 33 MHz with 12-clock operation

  • · PLCC, DIP, TSSOP or LQFP packages
  • · Extended temperature ranges
  • · Dual Data Pointers
  • · Security bits:

ROM (2 bits)

OTP (3 bits)

  • · Encryption array – 64 bytes
  • · Four interrupt priority levels
  • · Six interrupt sources
  • · Four 8-bit I/O ports
  • · Full-duplex enhanced UART

Framing error detection

Automatic address recognition

  • · Three 16-bit timers/counters T0, T1 (standard 80C51) and additional T2 (capture and compare)
  • · Programmable clock-out pin
  • · Asynchronous port reset
  • · Low EMI (inhibit ALE, slew rate controlled outputs, and 6-clock mode)
