Crack MCU ATMEGA128A Heximal

The first step to Crack MCU ATMEGA128A and extract the Heximal file out from its memory include flash and eeprom is decapsulate the microcontroller silicon package then there is possible to get access to the internal structure of the Microcontroller for copying;

The PSA and PS<2:0> bits (OPTION<3:0>) determine prescaler assignment and prescale ratio. When assigned to the Timer0 module, all instructions writing to the TMR0 register (e.g., CLRF 1, MOVWF 1, BSF 1,x, etc.) will clear the prescaler.

When assigned to WDT, a CLRWDT instruction will clear the prescaler along with the WDT. The prescaler is neither readable nor writable if copy avr microcontroller atmel.

On a Reset, the prescaler contains all ‘0’s. The prescaler assignment is fully under software control (i.e., it can be changed “on-the-fly” during program execution). To avoid an unintended device Reset, the following instruction sequence (Example 7-1) must be executed when changing the prescaler assignment from Timer0 to the WDT after pull avr mcu atmel.

To change the prescaler from the WDT to the Timer0 module, use the sequence shown in Example 7.2. This sequence must be used even if the WDT is disabled.

A CLRWDT instruction should be executed before switching the prescaler. The comparator module contains one Analog comparator. The inputs to the comparator are multiplexed with GP0 and GP1 pins. The output of the comparator can be placed on GP2. The CMCON0 register, shown in Register 8-1, controls the comparator operation.
