Crack IC dsPIC30F2011 Binary

Crack IC dsPIC30F2011 and extract the firmware out from the memory, the content will be in the format of Binary and can be copied to other blank Microcontroller which will provide the same functions;

Crack IC dsPIC30F2011 Binary

Crack IC dsPIC30F2011 Binary

High-Performance Modified RISC CPU:

Modified Harvard architecture

C compiler optimized instruction set architecture

Flexible addressing modes

84 base instructions

24-bit wide instructions, 16-bit wide data path

Up to 24 Kbytes on-chip Flash program space

Up to 2 Kbytes of on-chip data RAM

Up to 1 Kbytes of non-volatile data EEPROM

16 x 16-bit working register array

· Up to 30 MIPs operation:

– DC to 40 MHz external clock input

– 4 MHz-10 MHz oscillator input with  PLL active (4x, 8x, 16x)

· Up to 21 interrupt sources:

– 8 user selectable priority levels

– 3 external interrupt sources

– 4 processor trap sources

DSP Features:

· Dual data fetch

· Modulo and Bit-reversed modes

· Two 40-bit wide accumulators with optional saturation logic

· 17-bit x 17-bit single cycle hardware fractional/integer multiplier

· All DSP instructions are single cycle

– Multiply-Accumulate (MAC) operation

· Single cycle ±16 shift

Peripheral Features:

· High current sink/source I/O pins: 25 mA/25 mA

· Three 16-bit timers/counters; optionally pair up 16-bit timers into 32-bit timer modules

· 16-bit Capture input functions

· 16-bit Compare/PWM output functions:

· 3-wire SPI™ modules (supports four Frame modes)

· I2C™ module supports Multi-Master/Slave mode and 7-bit/10-bit addressing

· Up to two addressable UART modules with FIFO buffers

Analog Features:

· 12-bit Analog-to-Digital Converter (A/D) with:

– 100 Ksps conversion rate

– Up to 10 input channels

– Conversion available during Sleep and Idle

· Programmable Low Voltage Detection (PLVD)

· Programmable Brown-out Detection and Reset generation

Special Microcontroller Features:

· Enhanced Flash program memory:

– 10,000 erase/write cycle (min.) for industrial temperature range, 100K (typical)

· Data EEPROM memory:

– 100,000 erase/write cycle (min.) for industrial temperature range, 1M (typical)

· Self-reprogrammable under software control

· Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)

· Flexible Watchdog Timer (WDT) with on-chip low power RC oscillator for reliable operation

· Fail-Safe Clock Monitor operation:

– Detects clock failure and switches to on-chip low power RC oscillator

· Programmable code protection against IC breaking

· In-Circuit Serial Programming™ (ICSP™)

· Selectable Power Management modes:

– Sleep, Idle and Alternate Clock modes

CMOS Technology:

Low power, high speed Flash technology

Wide operating voltage range (2.5V to 5.5V)

Industrial and Extended temperature ranges

Low power consumption
