Crack IC dsPIC30F1010 Heximal

Crack IC dsPIC30F1010 and recover heximal file from the flash and eeprom memory, copy the program and data to blank Microcontroller to provide the same functions;

Crack IC dsPIC30F1010

Crack IC dsPIC30F1010

High-Performance Modified RISC CPU:

· Modified Harvard architecture

· C compiler optimized instruction set architecture

· 83 base instructions with flexible addressing modes

· 24-bit wide instructions, 16-bit wide data path

· 12 Kbytes on-chip Flash program space

· 512 bytes on-chip data RAM

· 16 x 16-bit working register array

· Up to 30 MIPS operation:

– Dual Internal RC

– 9.7 and 14.55 MHz (±1%) Industrial Temp

– 6.4 and 9.7 MHz (±1%) Extended Temp

– 32X PLL with 480 MHz VCO

– PLL inputs ±3%

– External EC clock 6.0 to 14.55 MHz

– HS Crystal mode 6.0 to 14.55 MHz

· 32 interrupt sources

· Three external interrupt sources

· 8 user-selectable priority levels for each interrupt

· 4 processor exceptions and software traps

DSP Engine Features:

· Modulo and Bit-Reversed modes

· Two 40-bit wide accumulators with optional saturation logic

· 17-bit x 17-bit single-cycle hardware fractional/integer multiplier

· Single-cycle Multiply-Accumulate (MAC) operation

· 40-stage Barrel Shifter

· Dual data fetch

Peripheral Features:

· High-current sink/source I/O pins: 25 mA/25 mA

· Three 16-bit timers/counters; optionally pair up 16-bit timers into 32-bit timer modules

· One 16-bit Capture input functions

· Two 16-bit Compare/PWM output functions

– Dual Compare mode available

· 3-wire SPI modules (supports 4 Frame modes)

· I2CTM module supports Multi-Master/Slave mode and 7-bit/10-bit addressing

· UART Module:

– Supports RS-232, RS-485 and LIN 1.2

– Supports IrDA® with on-chip hardware endec

– Auto wake-up on Start bit

– Auto-Baud Detect

– 4-level FIFO buffer

Power Supply PWM Module Features:

· Four PWM generators with 8 outputs

· Each PWM generator has independent time base and duty cycle

· Duty cycle resolution of 1.1 ns at 30 MIPS

· Individual dead time for each PWM generator:

– Dead-time resolution 4.2 ns at 30 MIPS

– Dead time for rising and falling edges

· Phase-shift resolution of 4.2 ns @ 30 MIPS

· Frequency resolution of 8.4 ns @ 30 MIPS

· PWM modes supported:

– Complementary

– Push-Pull

– Multi-Phase

– Variable Phase

– Current Reset

– Current-Limit

· Independent Current-Limit and Fault Inputs

· Output Override Control

· Special Event Trigger

· PWM generated ADC Trigger
