Crack HD64F3854HV Microprocessor Flash Program
Crack HD64F3854HV Microprocessor Flash Program and copy microcontroller firmware into other blank HITACHI HD64F3854HV MCU which will provide the same functions as original MCU;
CPU
Two-way general register configuration
• Eight 16-bit registers, or
• Sixteen 8-bit registers
High-speed operation
• Maximum clock rate (ø clock): 16 MHz at 5 V, 12MHz at 4 V or 10 MHz at 3 V
• 8- or 16-bit register-register add/subtract: 125 ns (16 MHz), 167 ns (12MHz), 200 ns (10 MHz)
• 8 8-bit multiply: 875 ns (16 MHz), 1167 ns (12MHz), 1400 ns (10 MHz)
• 16 8-bit divide: 875 ns (16 MHz), 1167 ns (12MHz), 1400 ns (10 MHz)
Streamlined, concise instruction set
• Instruction length: 2 or 4 bytes
• Register-register arithmetic and logic operations
• MOV instruction for data transfer between registers and memory
Instruction set features
• Multiply instruction (8 bits 8 bits)
• Divide instruction (16 bits 8 bits)
• Bit-accumulator instructions
• Register-indirect specification of bit positions
Memory • H8/3337Y, H8/3397: 60-kbyte ROM; 2-kbyte RAM
• H8/3336Y, H8/3396: 48-kbyte ROM; 2-kbyte RAM
• H8/3334Y, H8/3394: 32-kbyte ROM; 1-kbyte RAM
16-bit free-running timer (1 channel)
8-bit timer (2 channels)
PWM timer (2 channels)
Watchdog timer (WDT) (1 channel)
• One 16-bit free-running counter (can also count external events)
• Two output-compare lines
• Four input capture lines (can be buffered)
Each channel has
• One 8-bit up-counter (can also count external events)
• Two time constant registers
• Duty cycle can be set from 0 to 100%
• Resolution: 1/250
• Overflow can generate a reset or NMI interrupt
• Also usable as interval timer
Serial communication interface (SCI)
(2 channels)
I2C bus interface
(1 channel) [option]
• Asynchronous or synchronous mode (selectable)
• Full duplex: can transmit and receive simultaneously
• On-chip baud rate generator
• Conforms to Philips I2C bus interface
• Includes single master mode and slave mode
Host interface (HIF) • 8-bit host interface port
• Three host interrupt requests (HIRQ1, HIRQ11, HIRQ12)
• Regular and fast A20 gate output
• Two register sets, each with two data registers and a status register
