Low-Power Features:
· Power Managed modes:
– Run: CPU on, peripherals on
– Idle: CPU off, peripherals on
– Sleep: CPU off, peripherals off
· Power Consumption modes:
– PRI_RUN: 150 ìA, 1 MHz, 2V
– PRI_IDLE: 37 ìA, 1 MHz, 2V
– SEC_RUN: 14 ìA, 32 kHz, 2V
– SEC_IDLE: 5.8 ìA, 32 kHz, 2V
– RC_RUN: 110 ìA, 1 MHz, 2V
– RC_IDLE: 52 ìA, 1 MHz, 2V
– Sleep: 0.1 ìA, 1 MHz, 2V
· Timer1 Oscillator: 1.1 ìA, 32 kHz, 2V
· Watchdog Timer: 2.1 ìA
· Two-Speed Oscillator Start-up
Oscillators:
· Four Crystal modes:
– LP, XT, HS: up to 25 MHz
– HSPLL: 4-10 MHz (16-40 MHz internal)
· Two External RC modes, up to 4 MHz
· Two External Clock modes, up to 40 MHz
· Internal oscillator block:
– 8 user-selectable frequencies: 31 kHz, 125 kHz, 250 kHz, 500 kHz, 1 MHz, 2 MHz, 4 MHz, 8 MHz
– 125 kHz to 8 MHz calibrated to 1%
– Two modes select one or two I/O pins
– OSCTUNE – Allows user to shift frequency
· Secondary oscillator using Timer1 @ 32 kHz
· Fail-Safe Clock Monitor
– Allows for safe shutdown if peripheral clock stops
Peripheral Highlights:
· High current sink/source 25 mA/25 mA
· Three external interrupts
· Enhanced Capture/Compare/PWM (ECCP) module:
– One, two or four PWM outputs
– Selectable polarity
– Programmable dead time
– Auto-Shutdown and Auto-Restart
– Capture is 16-bit, max resolution 6.25 ns (TCY/16)
– Compare is 16-bit, max resolution 100 ns (TCY)
· Compatible 10-bit, up to 13-channel Analog-to-Digital Converter module (A/D) with programmable acquisition time
· Enhanced USART module:
– Supports RS-485, RS-232 and LIN 1.2
– Auto-Wake-up on Start bit
– Auto-Baud Detect
Special Microcontroller Features:
· 100,000 erase/write cycle Enhanced Flash program memory typical
· 1,000,000 erase/write cycle Data EEPROM memory typical
· Flash/Data EEPROM Retention: > 40 years
· Self-programmable under software control
· Priority levels for interrupts
· 8 x 8 Single-Cycle Hardware Multiplier
· Extended Watchdog Timer (WDT):
– Programmable period from 41 ms to 131s
– 2% stability over VDD and Temperature
· Single-supply 5V In-Circuit Serial Programming™ (ICSP™) via two pins
· In-Circuit Debug (ICD) via two pins
· Wide operating voltage range: 2.0V to 5.5V
This family offers the advantages of all PIC18 microcontrollers – namely, high computational performance at an economical price – with the addition of high endurance Enhanced Flash program memory. On top of these features, the PIC18F1220/1320 family introduces design enhancements that make these microcontrollers a logical choice for many high-performance, power sensitive applications when reverse engineering microchip mcu pic16f77 eeprom.
All of the devices in the PIC18F1320 family incorporate a range of features that can significantly reduce power consumption during operation. Key items include:
· Alternate Run Modes: By clocking the controller from the Timer1 source or the internal oscillator block, power consumption during code execution can be reduced by as much as 90%.
· Multiple Idle Modes: The controller can also run with its CPU core disabled, but the peripherals are still active. In these states, power consumption can be reduced even further, to as little as 4% of normal operation requirements.
· On-the-fly Mode Switching: The power managed modes are invoked by user code during operation, allowing the user to incorporate power-saving ideas into their application’s software design.
· Lower Consumption in Key Modules: The power requirements for both Timer1 and the Watchdog Timer have been reduced by up to 80%, with typical values of 1.1 and 2.1 ìA, respectively.
