Crack STM8S003F3 Microcontroller Memory include recover flash and eeprom memory of MCU stm8s003 and locate the security fuse bit, then copy embedded flash program and eeprom data from microprocessor chip;

Communications interfaces

• UART with clock output for synchronous operation, SmartCard, IrDA, LIN master mode
• SPI interface up to 8 Mbit/s
• I2C interface up to 400 Kbit/s

Analog to digital converter (ADC)

• 10-bit ADC, ± 1 LSB ADC with up to 5 multiplexed channels, scan mode and analog watchdog

I/Os

Up to 28 I/Os on a 32-pin package including 21 high-sink outputs

Highly robust I/O design, immune against current injection

Development support

Embedded single-wire interface module (SWIM) for fast on-chip programming and non-intrusive debugging which is an critical step for cracking mcu stm32f103vet6 memory.

This datasheet contains the description of the STM8S003F3/K3 value line features, pinout, electrical characteristics, mechanical data and ordering information.

For complete information on the STM8S microcontroller memory, registers and peripherals, please refer to the STM8S and STM8A microcontroller families reference manual (RM0016).

For information on programming, erasing and protection of the internal Flash memory please refer to the PM0051 but it’s not the standard way to extract code from arm mcu stm32f101rb memory (How to program STM8S and STM8A Flash program memory and data EEPROM).

For information on the debug and SWIM (single wire interface module) refer to the STM8 SWIM communication protocol and debug module user manual (UM0470).

For information on the STM8 core, please refer to the STM8 CPU programming manual (PM0044).
