Crack IC ATmega644PA Heximal
Crack IC ATmega644PA Heximal starts from disable the security fuse bits, read the program and data out from flash and eeprom, copy the firmware into blank Mcu;
Crack IC ATmega644PA Heximal
The Watchdog Timer is clocked from a separate On-chip Oscillator that runs at 1 MHz. This is the typical value at VCC = 5V. See “Typical Characteristics” on page 66 for typical values at other VCC levels. By controlling the Watchdog Timer prescaler.
the Watchdog Reset interval can be adjusted from 16 to 2048 ms, as shown in Table 15. The WDR (Watchdog Reset) instruction resets the Watchdog Timer.
Eight different clock cycle periods can be selected to determine the reset period. If the reset period expires without another Watchdog Reset, the ATtiny15L resets and executes from the reset vector.
For timing details on the Watchdog Reset, refer to page 17. To prevent unintentional disabling of the Watchdog, a special turn-off sequence must be followed when the Watchdog is disabled.
Refer to the description of the Watchdog Timer Control Register for details.
· Bits 7..5 – Res: Reserved Bits
These bits are reserved bits in the ATtiny15L and will always read as zero.
· Bit 4 – WDTOE: Watchdog Turn-off Enable
This bit must be set (one) when the WDE bit is cleared. Otherwise, the Watchdog will not be disabled. Once set, hardware will clear this bit to zero after four clock cycles. Refer to the description of the WDE bit for a Watchdog disable procedure.
· Bit 3 – WDE: Watchdog Enable
When the WDE is set (one), the Watchdog Timer is enabled and if the WDE is cleared (zero), the Watchdog Timer function is disabled. WDE can be cleared only when the WDTOE bit is set (one). To disable an enabled Watchdog Timer, the following procedure must be followed:
1. In the same operation, write a logical “1” to WDTOE and WDE. A logical “1” must be written to WDE even though it is set to one before the disable operation starts.
2. Within the next four clock cycles, write a logical “0” to WDE. This disables the Watchdog.
· Bits 2..0 – WDP2, WDP1, WDP0: Watchdog Timer Prescaler Bits 2, 1, and 0
The WDP2, WDP1 and WDP0 bits determine the Watchdog Timer prescaling when the Watchdog Timer is enabled.
